Description

2-way ceiling speakers with flared baffle and a low profile magnetic grille. The main driver with concentric directional tweeter is operated via a rotary control with 5 x 100V volume tappings and an 8 Ohms option. Mount into suspended or false ceilings using the 4 “dog-ear” mounts to achieve a discreet, high quality sound installation.
Dispersion angle 160°
Cutout 202mm
Mounting depth 99mm
Dimensions 102 x 232mmØ
Woofer 165mmØ (6.5″)
Tweeter 38mmØ (1.5″)
Frequency response 70Hz – 20kHz
Power max. : 8 Ohms 100W
Power rms : 8 Ohms 50W
Power rms : 100V line 20W
SPL @ 1W/1m 87dB (±2dB)
Tappings 2.5, 5, 10, 15, 20W & 8 Ohms
Weight 1.31kg
