Description

Desktop paging station with gooseneck microphone mounted via XLR into a base unit with a built-in dual amplifier. Each amplifier output has screw terminal speaker connections and can power a single 8 Ohm speaker or two 8 Ohm speakers wired in parallel (4 Ohm minimum load each output) and can be operated as a stereo Left + Right amplifier or as 2 separate zones. An AUX input on 3.5mm jack can accept a stereo line input for background music with its own volume control and is present on both channels permanently. A separate volume control governs the microphone level and there is a pre-set override that temporarily mutes the AUX input when announcements are being made. The paging process involves selecting one or both output channels via the buttons on the top panel and then pressing the “Page” button, which gives the option of paging just a single area or all areas where the speakers are installed. A simple and easy-to-use solution for where space is limited or an uncomplicated paging system is required.
Power supply 16Vdc, 4A power adaptor (included)
Output power @ 4 Ohms 2 x 30W
Output power @ 8 Ohms 2 x 15W
Auxiliary input Stereo 3.5mm jack
Speaker outputs Screw terminals (removeable Euroblock)
Dimensions 450 x 140 x 100mm (assembled)
Weight 552g
Microphone : connector XLR
