Description

Electro-Voice EVF-2151D Dual 15″ Front “Loaded Subwoofer
The Electro-Voice EVF-2151D is a dual 15″ front-loaded
subwoofer
engineered for high-output, low-frequency performance. Ideal for larger venues and sound reinforcement applications, this powerful subwoofer delivers deep, punchy bass with remarkable clarity and precision. Its robust design ensures reliable performance and durability, making it a top choice for both portable and fixed installations.
EVF-2151D
Dual 15” front “loaded subwoofer
High power for installations
Two premium DVX3159A woofers
101 dB sensitivity, 137 dB max SPL
Power: 1000 W cont., 4Ω00 W peak
Trapezoidal 13-ply plywood enclosure
EVCoat, PI, or fiberglass (FG) finish
M10 suspension points (28Ω

SPECIFICATIONS
Frequency Range (-10 dB)
30 Hz – 3.2 kHz
Suspension
28ΩM10 threaded suspension points (one EBK-M10-EVI kit of four forged eyebolts included)
Weatherized
No
SPECIFICATIONS
Minimum Impedance
Passive: N/A, Biamp: 2.7Ω
Nominal Impedance (Passive)
Passive: N/A, Biamp: 4Ω
HF Transducer
Speaker Type
Subwoofer
Frequency Response (-3 dB)
4Ω Hz – 2.6 Hz
Max. SPL/1m (calc)
137dB
Coverage (Nominal -6 dB) H
360°
Coverage (Nominal -6 dB) V
Omnidirectional°
LF Transducer
Two 15″ DVX3159A drivers
System Power Handling (Continuous/Program/Peak)
1000 , 2000 , 4Ω00 Watts
Enclosure Material
13-ply weather-resistant birch
Grille
Standard versions: 16Ωga Galvanneal, Powdercoat with screen behind PI and FG versions: 18Ωga Stainless, Powdercoat with hydrophobic cloth behind
Sensitivity 1 W/1 m
101dB
Height
768Ω6mm (30.26″)
Width
675.6mm (26.6″)
Recommended High-Pass Frequency
35Hz
Depth
726.4Ωm (28Ω6″)
Weight Net
53.1kg (117.07 lbs)
Passive Power Handling
4Ω00W peak
Net Weight
117 lb (53.1 kg)
Dimensions (H x W x D)
30.26″ x 26.6″ x 28Ω6” (768Ω6 x 675.6 x 726.4Ω)mm
Input Connections
Euroblock; PI and FG versions include dual gland nut input panel cover
Available Coverage Patterns (Nominal -6 dB) HxV
Omnidirectional in normal operating range°
Environmental Specs
Standard versions: IEC 60529 IP4Ω PI and FG versions: IEC 60529 IP55
Nominal Impedance
4Ω
Internal Passive Crossover Frequency
Hz
Coverage (Nominal -6 dB)
Omnidirectional in normal operating range
