Description

NewHank Workmate stereo mixer/pre-amplifier and smart media player.
Workmate
WORKMATE
a complete stereo mixer/pre-amplifier and smart media player. 4 volume/channel faders and the possibility of connecting 9 external devices, including 2 record players. Switching between these devices is easily done thru Select Switches on the front.
KEY FEATURES
Compact 2u low noise audio design
4 Line control channels plus separate Mic section
2 stereo phono, 7 stereo Line and 3 Mic inputs
2-band equalizer per channel
Stereo Master audio out on both RCA and balanced XLR
Balanced stereo Booth output on 6.3MM connectors
Stereo record output on RCA connectors
Master balance control
CUE per channel plus gain control
The player section:
Smart Media Player
Select play from USB, SD (both max 32GB) and thru Bluetooth
Plays both WAV and MP3 files
All, Single, Repeat and Random Play
SPECIFICATIONS
Power Consumption:
12W typical, 21W w/ full headphone output.
Power Supply:
Integrated transformer AC 230V-50Hz.
Weight:
3 kg
Mic:
600 ohm input impedance unbalanced
Line:
9V rms max
Dimensions:
19″ 2he Rack mount, Front 483x88mm Rear
Line/Aux:
10Kohm input impedance
Package Dimension:
555 x 325 x 470 mm
Operating Temperature:
5 to 35 deg. CC
Humidity:
25 to 85%. (Non-condensing)
Storage Temperature:
-20 to 60 deg. C
