NEXT-PROAUDIO PFA15 Active Full-Range Speaker and Monitor

Product Overview

The NEXT-PROAUDIO PFA15 Active Full-Range Speaker and Monitor is an active 15″ speaker engineered specifically for installations, musicians, and DJs who demand high output, dynamics, and exceptional fidelity at a competitive price. This makes it an affordable professional solution without compromising on performance.

Recommended for both fixed installations and mobile applications, the NEXT-PROAUDIO PFA15 Active Full-Range Speaker and Monitor is equally effective as a stage monitor or as a compact FOH system. It delivers impressive 132dB peak SPL with a frequency response of 54Hz to 18kHz, powered by a high-efficiency amplifier module with advanced digital processing.

The speaker employs premium-quality multi-plywood with a hardening, durable, and scratch-resistant coating, fully rotatable constant directivity HF horns to adjust HxV angle coverage, and custom-made speaker drivers. The integration with high-efficiency DPAmplifier modules and advanced digital processing sets a new standard for distortion, noise, and thermal efficiency.

Product Description

Active Two-Way Speaker and Monitor

The NEXT-PROAUDIO PFA15 Active Full-Range Speaker and Monitor represents the perfect balance of professional performance, versatility, and value. Designed for installations, musicians, and DJs, this speaker delivers high output and dynamics with extreme linearity and fidelity.

Premium Construction

The NEXT-PROAUDIO PFA15 Active Full-Range Speaker and Monitor is built with premium-quality multi-plywood featuring a hardening, durable, and scratch-resistant coating. This ensures the cabinet withstands the rigours of both touring and permanent installation.

The speaker features fully rotatable constant directivity HF horns, allowing you to adjust the HxV angle coverage to suit any venue or application. The 90° x 60° user-rotatable coverage pattern provides flexible deployment options.

Custom-Made Speaker Drivers

The NEXT-PROAUDIO PFA15 Active Full-Range Speaker and Monitor incorporates custom-made speaker drivers for optimal performance:

• Low Frequency Driver: 1 x 15″ (380mm) with 3″ (76mm) voice coil

• High Frequency Driver: 1 x 1″ (25mm) exit with 1.75″ (44mm) voice coil, custom compression driver

High-Efficiency Amplification

The integration with high-efficiency DPAmplifier modules and advanced digital processing sets a new standard for distortion, noise, and thermal efficiency.

Amplifier Specifications:

• Technology: 2 channel switched mode Class AB with DSP

• LF Section Power: RMS 400W / Program 540W / Peak 1080W

• HF Section Power: RMS 100W / Program 135W / Peak 270W

Advanced Digital Processing

The NEXT-PROAUDIO PFA15 Active Full-Range Speaker and Monitor features a controlled networkable DSP with 24bit/48kHz processing.

DSP Adjustable Parameters:

• 6 PEQ

• Delay

• HPF

• LPF

• Bass Enhancer

• Level

• Polarity

• Mute

DSP Presets: 6 Factory and 2 User, selectable via software or rear panel switch.

Plug and Play Simplicity

A surprisingly simple handling concept lets you plug in and play straightaway. Configure the system by selecting the right preset and let the speaker do the rest. The presets can be edited and stored in 2 USER memories.

Control and Connectivity

Control Type: Via RS485 and supplied software “SOUNDWARE”

Connectors:

• Signal: 2 x XLR

• Power: 2 x powerCON

Power Input: 90V – 245V
Power Consumption: 550W

Key Advantages

• Active two-way speaker and monitor

• 15″ custom LF driver with 3″ voice coil

• 1″ exit custom HF compression driver with 1.75″ voice coil

• 126dB / 132dB maximum SPL (Full-Space, calculated)

• Frequency response from 54Hz to 18kHz (-6dB)

• 90° x 60° user-rotatable coverage

• 2-channel switched mode Class AB amplifier with DSP

• LF power: 400W RMS / 540W Program / 1080W Peak

• HF power: 100W RMS / 135W Program / 270W Peak

• Networkable DSP 24bit/48kHz

• 6 PEQ, delay, HPF, LPF, Bass Enhancer, Level, Polarity, Mute

• 6 factory presets and 2 user memories

• RS485 control via SOUNDWARE software

• Premium multi-plywood enclosure with scratch-resistant coating

• Effective as stage monitor or compact FOH system

Key Features

• Active Two-Way Speaker and Monitor

• 15″ (380mm) custom LF driver with 3″ (76mm) voice coil

• 1″ (25mm) exit custom HF compression driver with 1.75″ (44mm) voice coil

• Frequency response: 54Hz – 18,000Hz (-6dB)

• Nominal coverage: 90° x 60° user rotatable

• Maximum SPL: 126dB program / 132dB peak (Full-Space, calculated)

• 2-channel switched mode Class AB amplifier with DSP

• LF Power: RMS 400W / Program 540W / Peak 1080W

• HF Power: RMS 100W / Program 135W / Peak 270W

• Controlled Networkable DSP 24bit/48kHz

• DSP Adjustable Parameters: 6 PEQ, delay, HPF, LPF, Bass Enhancer, Level, Polarity, Mute

• DSP Presets: 6 Factory and 2 User

• Control: Via RS485 and SOUNDWARE software

• Power Input: 90V – 245V

• Mains Connector: Signal: 2 x XLR; Power: 2 x powerCON

• Power Consumption: 550W

• Premium multi-plywood enclosure with hardening, durable, scratch-resistant coating

• Fully rotatable constant directivity HF horn

• Effective as stage monitor or compact FOH system

• Made in Europe

Specifications

Applications

The NEXT-PROAUDIO PFA15 Active Full-Range Speaker and Monitor is perfect for:

• Fixed installations

• Mobile applications

• Stage monitor use

• Compact FOH systems

• Musicians and DJs

• Live sound reinforcement

• Corporate AV events

• Houses of Worship

• Bars and clubs

• Theatres and performance venues

• Any application requiring high output and fidelity from a versatile active speaker

Why Choose the NEXT-PROAUDIO PFA15 Active Full-Range Speaker and Monitor?

The NEXT-PROAUDIO PFA15 Active Full-Range Speaker and Monitor represents the perfect balance of professional performance, versatility, and value. With its 132dB peak SPL, 15″ custom LF driver, and 1″ exit custom HF compression driver, this speaker delivers the high output and dynamics that professional applications demand.

The fully rotatable constant directivity HF horn with 90° x 60° coverage allows you to adjust the HxV angle to suit any venue, while the premium multi-plywood enclosure with scratch-resistant coating ensures durability for both touring and installation.

The 2-channel switched mode Class AB amplifier with DSP delivers 400W RMS to the LF section and 100W RMS to the HF section, with advanced DSP processing including 6 PEQ, delay, HPF, LPF, Bass Enhancer, Level, Polarity, and Mute. The 6 factory presets and 2 user memories make it easy to configure the system for any application.

With RS485 control via the supplied SOUNDWARE software, the NEXT-PROAUDIO PFA15 Active Full-Range Speaker and Monitor can be integrated into larger networked systems, making it ideal for installations requiring remote control and monitoring.

Whether you’re a musician looking for a reliable stage monitor, a DJ needing a compact FOH system, or an installer specifying a versatile active speaker, the NEXT-PROAUDIO PFA15 Active Full-Range Speaker and Monitor delivers the performance, flexibility, and value you need.
