Description
Rondson AM120 RM CD 2 120W 4 Zone Amplifier with 24V DC Backup CD Player USB SD FM Bluetooth
Four Zone Control with CD Player and Battery Backup
The Rondson AM120 RM CD 2 is a 120W four zone mixer amplifier designed for venues that need independent audio areas. Think pubs with a bar, dining room and function room. Think schools with separate hall, canteen and corridor zones. Think health clubs with gym, pool, studio and lounge.
Each zone turns on or off individually. Press the ALL button to send music everywhere at once.
The built in CD player sets this unit apart. Most commercial amplifiers dropped CD players years ago. But schools still have CD collections. Churches still use CD backing tracks. Community centres still get CDs from speakers. This amp keeps them in the game.
24V DC Backup Keeps You Live
Mains power fails. The amplifier does not. Switch to 24V DC battery backup instantly. Emergency announcements still reach every zone. Fire alarms still page. Security messages still go out. For public buildings, this is not optional.
Three Mic Inputs with Phantom
| Input | Type | Features |
|---|---|---|
| MIC 1 | XLR | 18V phantom power, Talk Over priority |
| MIC 2 | 6.35mm jack | Switchable to line input |
| MIC 3 | 6.35mm jack | Switchable to line input |
MIC 1 triggers Talk Over. Speak into it and background music ducks automatically. Announcements cut through every time.
Complete Media Suite
One unit replaces five separate boxes:
| Source | What It Plays |
|---|---|
| CD player | Standard audio CDs |
| FM tuner | Local radio stations |
| USB port | MP3 files |
| SD card slot | MP3 files |
| Bluetooth | Stream from any phone tablet laptop |
Four Zone Control
Each zone has its own REC OUT. Record what plays in the bar without recording what plays in the function room.
Select zones individually or hit ALL for whole venue coverage.
Visual Feedback
Each zone has its own VU meter. See output levels at a glance. No guessing which zone is clipping.
Tone Shaping
Bass and treble controls. ±10 dB at 100 Hz and 10 kHz.
Music Cut Contact
Dry contact input mutes the entire system. Connect to fire alarm. Connect to doorbell. Connect to any external trigger.
Protection Circuitry
Thermal protection. Overload protection. Short circuit protection. Fan cooling.
What’s in the Box
| Item | Detail |
|---|---|
| Amplifier unit | 482 x 340 x 88 mm |
| 19 inch rack brackets | Included |
| Power cord | IEC |
| Remote control | For media player |
| Weight | 12 kg |
Where to Install
| Venue | Zone Application |
|---|---|
| Pubs | Bar, dining, function room, beer garden |
| Schools | Main hall, canteen, corridors, gymnasium |
| Health clubs | Gym floor, studio, pool area, lounge |
| Restaurants | Main dining, private room, bar, terrace |
| Hotels | Lobby, conference room, restaurant, bar |
| Community centres | Main hall, meeting room, cafe, office |
| Churches | Sanctuary, hall, kitchen, outdoor area |
| Care homes | Lounge, dining room, corridors, garden room |
| Shops | Sales floor, changing rooms, stockroom, office |
| Sports clubs | Clubhouse, changing rooms, function room, bar |
| Village halls | Main hall, kitchen, meeting room, storage |
Sales & Installation
Sales – Complete amplifier including CD player, remote and rack brackets. Call or email for pricing.
Installation – Full service including zone configuration, speaker wiring, battery backup integration and staff training on zone controls.
Get a Quote
Volume Music Solutions supplies and installs multi zone amplifier systems for pubs, schools, health clubs, restaurants, hotels, community centres, churches, care homes, shops, sports clubs, village halls and any venue requiring independent audio zones with backup power.
Based in Buckingham. Covering the whole UK.
